产品范围

　　蒸发量：2-35t/h，设计压力：0.7-2.5MPa

　　锡能SZS型系列水煤浆蒸汽、热水锅炉是新一代环保产品。具有燃料成本低和污染物排放低的特点，是燃油、燃煤锅炉的替代产品。该系列锅炉为自然循环、室燃水管蒸汽锅炉，微负压燃烧，平衡通风。本体采用纵向布置得上、下两只锅筒，燃烧器布置在前墙，水煤浆在炉膛内充分燃烧（燃烧效率>98%），产生的高温烟气经炉膛出口横向冲刷对流管束，再经布置在锅炉后部的空气预热器换热，通过脱硫除尘器的处理，然后由引风机将烟气送至烟囱排入大气。

　　水煤浆燃烧效率（>98%），锅炉设计热效率高（接近90%）；

　　排放符合国家《锅炉大气污染物排放标准》一类地区环保要求；

　　采用前置稳燃炉膛结构和合理的炉膛截面、容积，使产品能适应多种水煤浆的燃烧，并有效控制炉膛的结焦现象。

　　Product Range

　　Evaporation capacity: 2-35t/h, design pressure: 0.7-2.5MPa

　　Tin to SZS Series CWM steam, hot water boiler is a new generation of environmentally friendly products. With low fuel costs and low emissions of pollutants, fuel, coal-fired boiler is the best alternative. The series of boilers for natural circulation, room steam pipe steam boiler, micro-negative pressure combustion, balanced ventilation. The body is arranged longitudinally with two lower drums. The burner is arranged on the front wall and the coal-water slurry is fully burned in the furnace (combustion efficiency> 98%). The generated high-temperature flue gas scours the convection tube bundle laterally through the furnace outlet. The air preheater arranged at the back of the boiler exchanges heat and is treated by the desulfurization precipitator. Finally, the induced draft fan sends the flue gas to the chimney to discharge into the atmosphere.

　　CWS combustion efficiency (> 98%), boiler design thermal efficiency (nearly 90%);

　　Emissions comply with the requirements of the State Environmental Protection Standard for Emission Standards of Air Pollutants for Boilers;

　　Pre-stabilizing furnace chamber structure and a reasonable cross-section of the furnace, the volume, so that the product can adapt to a variety of coal-water slurry combustion, and effectively control the furnace coke phenomenon.
